PV Energy System A Class 22.5KG 24V 300W Polycrystalline Solar Panel Model JCPVS-24V1KW-S300/40L PV input Solar panel Poly Crystalline A class Work voltage 36V Open voltage 42V power 300W Cable 10M(MC4) Size(mm) 1950mmX984mmX40mm Weight 22.5KG MPPT Solar charge Controller MPPT controller Charging current(MAX) 20A Over-discharge protection 21.0V Over-discharge resume 25.2V Over-voltage protection 32.0V Over-voltage resume 30.0V Balance charge protection 29.2V Battery(integrated) FeLiPO4 battery 25.6V 40AH Output DC load 24V output 10A USB-5V 3A voltage 21V~30V 5W LED 3PCS(Line length5M) AC OUTPUT voltage 220V/ 50HZ;110V/60HZ Power 1000W Over load protection 1100W Short-circuit protection 2000VA Output wave form Pure sine wave General parameters Weight 70KG Shell Protection grade IP21 Size(mm) 400*248*410 Environment temperature -25℃~55℃ Humidity ≤85% Introduction: This manual book introduces the installation and operation of this solar system, for your convenience, please kindly read following stuff carefully. 1. Please read the guide carefully before installation and operation. 2. Please kindly reserve this manual for record. 3. Please attach this manual if you need further delivery. System feature: 1. Integrated battery, charge controller and inverter in one machine 2. MPPT charge control process 3. Power DC loads 4. LCD display with operation status 5. USB plug 5V 6. AC plug Structure: This Mobile Power includes the following parts: 1. Metallic handle, easy to move 2. Display with battery capacity and charging status 3. Real-time status display of DC output 4. False indicator as red light 5. Master switch. Cut off battery supply 6. SET switch of DC output or not 7. DC socket. It should connect the DC load. 8. USB-5V load. 9. Aviation socket to connect the solar panels. 10. Universal AC socket LED indicator: LED Display Status Green LED(charge) on charging process now Yellow LED(full) on Charging completed Red LED(low) on Battery under voltage
